Çift Kademeli Santrifüj Pompalar

Aflow 220H26 Çift Kademeli Blower
Aflow 420H36 Çift Kademeli Blower
Model: 2RB 220-7HH26
Stage: Double Stage
Freq: 50 (Hz)
Power: 0.7 (Kw)
Airflow: 85 (m³/h)
TH.CL: IP55
Pressure: 240 (mbar)
IN.CL: F or H
Vacuum: -210 (mbar)
N.weight: 15 (kg)
Inlet/outlet: G 1 ¼ (inch)
Sound: 55 dB(A)
Dimension for Side Channel Blower(L*W*H): 316 × 458 × 270 (mm)
Model: 2RB 420-7HT36
Stage: Double Stage
Freq: 50 (Hz)
Power: 1.5 (Kw)
Airflow: 150 (m³/h)
TH.CL: IP55
Pressure: 270 (mbar)
IN.CL: F or H
Vacuum: -270 (mbar)
N.weight: 24 (kg)
Inlet/outlet: G 1 ½ (inch)
Sound: 66 dB(A)
Dimension for Side Channel Blower(L*W*H): 401 × 485 × 315 (mm)
Katalog
Katalog
Aflow 420H36 Çift Kademeli Blower
Aflow 420H46 Çift Kademeli Blower
Model: 2RB 420-7HT36
Stage: Double Stage
Freq: 50 (Hz)
Power: 1.5 (Kw)
Airflow: 150 (m³/h)
TH.CL: IP55
Pressure: 270 (mbar)
IN.CL: F or H
Vacuum: -270 (mbar)
N.weight: 24 (kg)
Inlet/outlet: G 1 ½ (inch)
Sound: 66 dB(A)
Dimension for Side Channel Blower(L*W*H): 401 × 485 × 315 (mm)
Model: 2RB 420-7HH46
Stage: Double Stage
Freq: 50 (Hz)
Power: 2.2 (Kw)
Airflow: 150 (m³/h)
TH.CL: IP55
Pressure: 420 (mbar)
IN.CL: F or H
Vacuum: -330 (mbar)
N.weight: 27 (kg)
Inlet/outlet: G 1 ½ (inch)
Sound: 66 dB(A)
Dimension for Side Channel Blower(L*W*H): 401 × 485 × 315 (mm)
Katalog
Katalog
Aflow 520H46 Çift Kademeli Blower
Aflow 520H57 Çift Kademeli Blower
Model: 2RB 520-7HT46
Stage: Double Stage
Freq: 50 (Hz)
Power: 3.0 (Kw)
Airflow: 230 (m³/h)
TH.CL: IP55
Pressure: 360 (mbar)
IN.CL: F or H
Vacuum: -340 (mbar)
N.weight: 40 (kg)
Inlet/outlet: G 2 (inch)
Sound: 72 dB(A)
Dimension for Side Channel Blower(L*W*H): 500 × 597 × 360 (mm)
Model: 2RB 520-7HH57
Stage: Double Stage
Freq: 50 (Hz)
Power: 4.0 (Kw)
Airflow: 230 (m³/h)
TH.CL: IP55
Pressure: 440 (mbar)
IN.CL: F or H
Vacuum: -390 (mbar)
N.weight: 44 (kg)
Inlet/outlet: G 2 (inch)
Sound: 72 dB(A)
Dimension for Side Channel Blower(L*W*H): 499 × 597 × 371 (mm)
Katalog
Katalog
Aflow 720H37 Çift Kademeli Blower
Aflow 720H47 Çift Kademeli Blower
Model: 2RB 720-7HT37
Stage: Double Stage
Freq: 50 (Hz)
Power: 4.00 (Kw)
Airflow: 320 (m³/h)
TH.CL: IP55
Pressure: 320 (mbar)
IN.CL: F or H
Vacuum: -340 (mbar)
N.weight: 53 (kg)
Inlet/outlet: G 2 (inch)
Sound: 73 dB(A)
Dimension for Side Channel Blower(L*W*H): 566 × 639 × 410 (mm)
Model: 2RB 720-7HT47
Stage: Double Stage
Freq: 50 (Hz)
Power: 5.5 (Kw)
Airflow: 320 (m³/h)
TH.CL: IP55
Pressure: 460 (mbar)
IN.CL: F or H
Vacuum: -420 (mbar)
N.weight: 70 (kg)
Inlet/outlet: G 2 (inch)
Sound: 73 dB(A)
Dimension for Side Channel Blower(L*W*H): 607 × 639 × 410 (mm)
Katalog
Katalog
Aflow 720H57 Çift Kademeli Blower
Aflow 820H27 Çift Kademeli Blower
Model: 2RB 720-7HT57
Stage: Double Stage
Freq: 50 (Hz)
Power: 7.5 (Kw)
Airflow: 320 (m³/h)
TH.CL: IP55
Pressure: 610 (mbar)
IN.CL: F or H
Vacuum: -420 (mbar)
N.weight: 77 (kg)
Inlet/outlet: G 2 (inch)
Sound: 73 dB(A)
Dimension for Side Channel Blower(L*W*H): 607 × 639 × 410 (mm)
Model: 2RB 820-7HT27
Stage: Double Stage
Freq: 50 (Hz)
Power: 7.5 (Kw)
Airflow: 520 (m³/h)
TH.CL: IP55
Pressure: 350 (mbar)
IN.CL: F or H
Vacuum: -380 (mbar)
N.weight: 169 (kg)
Inlet/outlet: G 2 ½ (inch)
Sound: 74 dB(A)
Dimension for Side Channel Blower(L*W*H): 625 × 799 × 490 (mm)
Katalog
Katalog
Aflow 820H37 Çift Kademeli Blower
Aflow 840H37 Çift Kademeli Blower
Model: 2RB 820-7HT37
Stage: Double Stage
Freq: 50 (Hz)
Power: 11.0 (Kw)
Airflow: 520 (m³/h)
TH.CL: IP55
Pressure: 560 (mbar)
IN.CL: F or H
Vacuum: -430 (mbar)
N.weight: 205 (kg)
Inlet/outlet: G 2 ½ (inch)
Sound: 74 dB(A)
Dimension for Side Channel Blower(L*W*H): 695 × 799 × 490 (mm)
Model: 2RB 840-7JT37
Stage: Double Stage
Freq: 50 (Hz)
Power: 11.0 (Kw)
Airflow: 900 (m³/h)
TH.CL: IP55
Pressure: 320 (mbar)
IN.CL: F or H
Vacuum: -280 (mbar)
N.weight: 200 (kg)
Inlet/outlet: G 2 ½ (inch)
Sound: 74 dB(A)
Dimension for Side Channel Blower(L*W*H): 754 × 500 × 550 (mm)
Katalog
Katalog
Aflow 820H47 Çift Kademeli Blower
Aflow 840H37 Çift Kademeli Blower
Model: 2RB 820-7HT47
Stage: Double Stage
Freq: 50 (Hz)
Power: 15.0 (Kw)
Airflow: 520 (m³/h)
TH.CL: IP55
Pressure: 670 (mbar)
IN.CL: F or H
Vacuum: -460 (mbar)
N.weight: 221 (kg)
Inlet/outlet: G 2 ½ (inch)
Sound: 74 dB(A)
Dimension for Side Channel Blower(L*W*H): 755 × 799 × 490 (mm)
